#Arduino pro mini serial port zip file

If your computer prompts for drivers, point it to the “drivers\FTDI USB Drivers” subfolder of the Arduino software, e.g.

Connect the other end of the cable into a USB port on your PC/Mac.

Connect the mini-USB end of the cable into the FTDI Basic Breakout.

#Arduino pro mini serial port zip file

Unzip the zip file to somewhere like C:\ (on Windows), so you will end up with a folder like C:\arduino-0022.

Get the Arduino software if you have not already.

SparkFun Electronics, and is released under the Creative CommonsĪttribution Share-Alike License. The original design can be found at This board is based off of the Arduino Pro designed by The fuse will trip when the current exceeds 500 mA on the input. The board comes with a resettable polyfuse on the power source.

Should you wish to update and/or replace the bootloader, there are ICSP (In-Circuit Serial Programming) pin-outs that can be used in combination with a header (sold separately) for the ATmega328P. The ATmega328P comes with the Arduino bootloader preloaded. Compatible with the Ethernet and Motor Controller Shields.Compatible with existing Arduino software libraries.ICSP header for programming microcontroller.

Flexible power source (lithium polymer battery or DC power).About 2/3 the size of the OSEPP™ Uno board.8-bit AVR RISC-based microcontroller running at 16 MHz.Lithium polymer battery or external DC power supply Pro users can choose to connect only the needed pins by mounting headers or soldering wires directly.Ģ.07 x 2.11 x 0.30 inches (52.5 x 53.5 x 7.5 mm) Unlike the Uno model this barebones board lacks headers, which gives this board a low profile. The OSEPP™ Pro board is tailored to more professional users who do not mind a build-it-yourself approach compared to the OSEPP™ Uno.
